1. What is swmm-api?
swmm-api is an open-source Python library that provides a low-level, real-time interface to the EPA Storm Water Management Model (SWMM). It allows Python developers to:
- Read, modify, and control SWMM simulations dynamically
- Access internal states of SWMM objects at each timestep
- Inject custom control logic for pumps, valves, inflows, or rain events
- Integrate SWMM models into automated workflows, simulations, or optimization loops
Unlike high-level tools like PySWMM, swmm-api provides direct memory access to the internal SWMM simulation, making it extremely powerful for real-time control, data assimilation, and fine-grained simulation manipulation.
It is developed and maintained by jbgo/swmm-api and supports SWMM5 engine integration across platforms.
#SwmmAPIUseCases
2. Major Use Cases of swmm-api
The swmm-api package offers advanced control and automation for stormwater simulations. It is best suited for professionals and developers requiring programmatic, stepwise control of the simulation process.
💧 2.1. Real-Time Control (RTC) of Urban Drainage Systems
- Implement sensor-driven control of gates, pumps, or regulators
- Integrate SCADA systems to drive SWMM control logic
- Update model parameters based on live weather or flow data
🧪 2.2. Calibration and Sensitivity Analysis
- Adjust parameters (e.g., catchment area, slope, or roughness) during runtime
- Run multiple simulation iterations programmatically
- Export results for analysis or optimization
📊 2.3. Research and Custom Simulation Scenarios
- Experiment with novel flow control strategies
- Apply machine learning to predict optimal setpoints
- Conduct storm event scenario testing with variable rainfall profiles
📡 2.4. Data Assimilation and Digital Twins
- Ingest real-time sensor data (rainfall, depth, flow) and simulate system response
- Use SWMM as a digital twin of a physical urban stormwater system
- Validate and refine predictive models in real-time
🧰 2.5. Automation and Workflow Integration
- Integrate with CI/CD pipelines, APIs, or data dashboards
- Use in notebooks or remote simulations
- Combine with optimization libraries like
scipy.optimizeorpyomo
#SwmmAPIArchitecture
3. How swmm-api Works – Architecture Overview
The swmm-api package operates by directly interfacing with the SWMM5 engine’s compiled binary (usually swmm5.dll or swmm5.so) and accessing its simulation memory using Python’s ctypes module.
🧱 3.1. Architecture Layers
✅ A. SWMM Engine (Core)
- Original C-based SWMM5 engine (e.g., version 5.1.15 or newer)
- Responsible for time-based hydrologic/hydraulic simulations
- Processes
.inpfiles defining system topology and parameters
✅ B. swmm-api Memory Interface
- Loads SWMM engine dynamically using ctypes
- Attaches to the in-memory objects used during simulation
- Provides access to core SWMM structures like:
- Nodes
- Links
- Subcatchments
- Controls
✅ C. Python Interface Layer
- Offers Pythonic classes and methods to:
- Read simulation outputs in real time
- Set inflows, control settings, and time parameters
- Monitor water quality, depth, volume, and more
✅ D. User Script / Application
- Typically written in Python
- Drives the simulation loop, custom control logic, optimization, or logging
- Optionally visualizes results using
matplotlib,pandas, orPlotly
#SwmmAPIWorkflow
4. Basic Workflow of swmm-api
Here’s a high-level view of how a typical swmm-api based simulation workflow proceeds:
🔄 Simulation Loop Workflow
| Step | Action |
|---|---|
| 1. | Load and compile the SWMM5 engine (DLL or shared object) |
| 2. | Initialize simulation with .inp model |
| 3. | Step through the simulation in real-time (1 timestep at a time) |
| 4. | At each step, read/write values (e.g., depth, flow, rainfall) |
| 5. | Optionally modify parameters based on logic or inputs |
| 6. | Save results or visualize after simulation completes |
🔍 Access Points
getNodeParam,setLinkFlow,getRainfallstepSimulation,getSimulationTime,getWaterQuality- All access is low-level and performant (direct pointer access)
#GettingStartedWithSwmmAPI
5. Step-by-Step Guide to Using swmm-api
This guide assumes you’re familiar with SWMM .inp files and basic Python.
✅ Step 1: Install Dependencies
Clone the repository:
git clone https://github.com/jbgo/swmm-api.git
cd swmm-api
pip install -r requirements.txt
Install a compatible version of SWMM5 engine:
- Windows: download
swmm5.dll - Linux: compile
swmm5.so - Place it in your project directory or system path
✅ Step 2: Prepare a SWMM Model
Use EPA SWMM or QGIS plugin to create a .inp file defining:
- Subcatchments
- Junctions
- Pipes
- Control rules
- Simulation time and rainfall data
✅ Step 3: Initialize Simulation
from swmm_api.input_file import read_inp_file
from swmm_api.simulation import Simulation
inp = read_inp_file("model.inp")
sim = Simulation(inp)
sim.start()
✅ Step 4: Step Through Simulation
while not sim.is_finished():
sim.step_advance() # advance simulation
flow = sim.get_link_result('C1')['flow_rate']
depth = sim.get_node_result('J2')['depth']
print(f"Flow at C1: {flow:.2f} m³/s, Depth at J2: {depth:.3f} m")
✅ Step 5: Inject Custom Logic
if depth > 1.5:
sim.set_link_setting('C1', 0.3) # throttle valve
✅ Step 6: Post-Process and Visualize
import matplotlib.pyplot as plt
times = sim.get_times()
flows = sim.get_link_result('C1')['flow_rate_series']
plt.plot(times, flows)
plt.title("Flow Rate at Conduit C1")
plt.xlabel("Time")
plt.ylabel("Flow (m³/s)")
plt.show()
✅ Step 7: Advanced Uses
- Combine with sensor data via
requestsor MQTT - Integrate with Jupyter notebooks for interactive analysis
- Automate batch runs for calibration
